British Olympic legend selects Shaws for Windows & Doors in stunning barn conversion Read More
Origin Artisan Patio Sliding Door
The Ultra Slim OS-20
Minimal and sleek in design, the Artisan Slider OS-20 has ultra-slim sightlines of just 20mm and, being made from premium grade aluminium, it’s a combination that means less frame and more natural light, and makes for a truly breath-taking spectacle.
Made to your exact specification
No home is the same, each having its own unique character. Why should your doors be any different? Origin sliding doors are made bespoke to suit your needs.
- Overall Size – The size of your aperture. We will measure this for you.
- Configuration – How many individual doors you want in your configuration.
- Colour – Choose from over 150 RAL colours to suit your home style.
- Handle Style and Colour – Consider the model and subsequent colour of your handles.
Proudly manufactured in the United Kingdom at origin’s Buckinghamshire facility.
Discover our industry leading guarantees for complete peace of mind.
Our doors help your house stay warm in winter and cool in the summer.
We’re committed to your safety through compliance and accreditation initiatives.
A wide range of colour and finish options ensures that there is a style to suit your home.
Find out how our unbeatable delivery promises can help your project.
All Origin products are tailor-made to your requirements by a highly skilled team.
Origin doors benefit from the strength, resilience and versatility of our premium grade aluminium.
Expert engineering allows you to focus on enjoying the products rather than taking the time to maintain them.
The Origin OS- 20 Artisan Slider In Detail…
The Artisan Slider OS-20 is unique in its design and manufacturing process, which ultimately decides the panel sizes it can accommodate, and the slim sightlines it achieves
| OS-20 | |
|---|---|
Interlocker SightlineSize denotes glass to glass measurements |
20mm |
Sizes – Height(overall size) |
Min. 1600mm - Max. 3000mm |
Sizes – Width(overall size) |
Min. 1228mm - Max. 13196mm |
Popular Colours |
7016M |
Glazing Options |
Wet glazing (glass units are bonded to the frame using structural sealant) |
U-Value |
1.4W/m2K |
Guarantee |
Standard - Up to 10‑years frames and hardware, 5‑years on glass |
Interlocker Sightline
Size denotes glass to glass measurements
OS-20
20mm
Sizes – Height
(overall size)
OS-20
Min. 1600mm - Max. 3000mm
Sizes – Width
(overall size)
OS-20
Min. 1228mm - Max. 13196mm
Popular Colours
OS-20
7016M
Glazing Options
OS-20
Wet glazing (glass units are bonded to the frame using structural sealant)
U-Value
OS-20
1.4W/m2K
Guarantee
OS-20
Standard - Up to 10‑years frames and hardware, 5‑years on glass
Stay Secure and Safe..
An incredibly secure system offering a minimum of six points of locking to either the jamb or adjacent door, there’s only a handle on the inside of the OS-20 Artisan Slider, so there’s no lock on the outside for would-be intruders to pick.
The aluminium frame and e-toughened glass – which is tough to break as well as thermally efficient – makes it easier to open up your world, your way, with complete peace of mind.
A Wet glazed system for improved weather tightness…
The Artisan Slider OS-20 comes as a bonded system – sometimes referred to as a wet glazed system – which means the glass and frame comes as one unit. The benefits to this are that the doors have improved weather tightness and slimmer sightlines are achieved.
We have teamed up with internationally celebrated glass suppliers who share our dedication to making technologically advanced glass solutions, so that together, we can create a sliding door that’s incredibly secure, thermally efficient and aesthetically stunning.
Any size to suit your home…
Each individual panel can be up 2.2m wide and 3m tall (or 6m2 overall) with a maximum overall width of over 13m – the OS-20 is minimalistic and yet has the potential to give your home an entire wall of glass.
Handle Options
Offering an elegant and seamless finish, every Origin Artisan Slider is fitted with a streamlined handle. Available in five attractive colours, its architecturally striking and aesthetically pleasing design blends effortlessly into the frame while remaining hard-wearing and practical.
OS-20 Artisan Handles
9910G Hipca White
7015M Slate Grey
7016M Anthracite Grey
9005M Jet Black
Light Silver
The Origin Patio Sliding Door, transforms the way families enjoy their home - from inside to out
Patio Sliding Door configurations...
Explore the OS-20 Sliding Door configurations
Key:
O - Indicates Fixed Sash
X - Indicates Opening Sash
- Indicates Opening Direction
OX (1 fixed, 1 sliding) or XX (2 sliding)
OXX (1 fixed, 2 sliding) or XXX (3 sliding)
OXXO (2 fixed, 2 sliding) or XXXX (4 sliding)
OXXXXO (2 fixed, 4 sliding) or XXXXXX (6 sliding)
